UGREEN NASync DXP6800 Pro

Intel i5 1235u 10-Core CPU, 2 * 10GbE, 8K HDMI, 2 * TBT4, Diskless
Regular price $1,079.99
Sale price $1,079.99 Regular price $1,199.99
Save $120
  • Supports 3rd-Party Drives: UGREEN NASync is widely compatible with third-party hard drives, including those from Western Digital, Seagate, Toshiba, and more. Please check our compatibility list for full details.
  • Dual 10GbE Network Ports: Two 10GbE high-speed network ports that can be aggregated into 20G bandwidth for download speeds of up to 2500MB/s.
  • 12th Gen 10-core Intel® Core™ Processor: With a 12th Gen, 10-core 12-thread Intel® Core™ i5 Processor, processing performance is improved by leaps and bounds compared to previous processors.
  • 6-Bay, 196TB Massive Data Storage: Equipped with six SATA and two M.2 NVMe drive bays, the NASync DXP6800 Pro has a maximum storage capacity of up to 196TB. And supports JBOD/Basic/RAID0/RAID1/RAID5/RAID6/RAID10 RAID levels. Store thousands of HD movies, pictures, and documents, Making NASync a movie library, photo album, and file storage space all in one.
  • One, All-Inclusive App: Rather than downloading individual applications for specific functions, the NAS App incorporates these functions into one place. Access Storage Manager, Files, Photos and more, all from one convenient location.
  • Expandable 8GB DDR5 Memory: 8GB DDR5 4800MHz provide the latest in processing speeds and improved software and system performance.
  • AI Photo Album: Automatically organizes your photos by recognizing faces, scenes, objects, and locations. It can also instantly remove duplicates, freeing up storage space and saving you time. Explore the very latest AI Album features on the AI NAS page.

Pay with Ease

Visa Mastercard American Express PayPal Discover JCB Diners Club Union Pay Cartes Bancaires Klarna

Guaranteed Safe Delivery

Delivery ServiceDelivery ServiceDelivery Service
UGREEN NASync DXP6800 Pro with Expandable 8GB DDR5 Memory and 6-Bay, 160TB Massive Data Storage, equiped with 12th Gen 10-core Intel® Core™ Processor

UGREEN NASync DXP6800 Pro

Shipping icon Expected to be delivered within 5 days.
Regular price $1,079.99
Sale price $1,079.99 Regular price $1,199.99
Save $120
Shipping icon Expected to be delivered within 5 days.
UGREEN NASync DXP6800 Pro

UGREEN 6 bay NAS storage Intel Core i5 processor, including two 10GbE network ports, up to 196TB of storage (excluding storage drives), and expandable 8GB of DDR5 memory, two Thunderbolt4 Ports
UGREEN 6 bay NAS storage with Intel 12th Gen 10-core Intel processors

UGREEN 6 bay NAS storage 8GB DDR5 4800MHz memory module (expandable to 64GB) for enhanced multitasking and system performance.

UGREEN 6 bay NAS storage device with ultra-fast dual 10GbE network ports and dual Thunderbolt™ 4 ports for lightning-fast file transfers without the wait.

UGREEN 6 bay nas storage supports up to 196TB of memory with six HDD cartridges supporting 24TB capacity and two 8TB M.2 NVMe slots

UGREEN 6 bay NAS storage has one HDMI port (8K), two USB 3.2 Gen 1 ports (10Gb/s), two USB 2.0 ports (480Mb/s), two Thunderbolt™ 4 Ports ports, one SD Card insertion, two Ethernet ports (10Gb/s), and two USB 2.0 ports (480Mb/s). )




UGREEN AI NAS Management Software UGOS PRO, available on Windows, MacOS, Android, iOS, Web, and Smart TVs

Unified UGREEN NAS storage 6 bay app for cross-platform file management, media streaming, and photo access across phones, tablets, and PCs.

UGREEN NAS Storage 6 bay Integrated Smart Assistant: Search for landscapes, houses, vehicles or any of your favorite photos by simply typing in a keyword.

UGREEN NAS storage 6 bay Remote Access Sync photos in real time and access any of your files remotely, no matter how far you are from home.

UGREEN NAS storage 6 bay Multi-functional App Center featuring media tools, system utilities, and management solutions.




UGREEN NAS storage 6 bay Remote Access Sync photos in real time and access any of your files remotely, no matter how far you are from home.

UGREEN 6 bay nas storage centralized data management platform enabling secure team file sharing and collaborative workflows.

UGREEN 6 bay NAS storage Professional Data Security:  Firewall, High-Strength Encryption, and Security Manager, device has powerful safety features.

UGREEN storage 6 bay supports Docker software is used, and can be used to understand the current operation of the system through real-time data such as CPU utilization and memory occupation rate




Backing up important team files with UGREEN 6bay nas storage

Backup important team files with UGREEN 6bay nas storage for team collaboration

UGREEN 6bay nas storage Supports file transfer sharing no matter where team members are located

UGREEN 6bay nas storage is a strong supporter of backing up host files




Premium aluminum alloy chassis with numbered drive 6 bays, combining subtle aesthetics with enhanced durability and vibration-resistant stability.

Hard drive setup for UGREEN NAS storage is as simple as Simple Push/Pull Drive Tray for Easy Installation!

There are three options for UGREEN NAS storage cooling modes, “Default Mode,” “Silent Mode,” and “Full Speed Mode,” which intelligently adjusts the cooling power according to your device's needs, ensuring that your work is not affected by the sound of your device's cooling.

UGREEN NAS storage is equipped with a magnetic dust mesh filter that effectively removes filters and attracts dust to protect the cleanliness of the device

UGREEN 6bay NAS storage accessories include a power adapter, multiple cables, a user manual, a 3-year warranty card, two blue cooling strips, a small screwdriver and screws, all neatly arranged on a dark background.
.



Click here for more NAS Storage!

Comparison with Other UGREEN NASync

Drive Bays
6-Bay (SATA)
8-Bay (SATA)
4 Slots (M.2 NVMe)
2-Bay (SATA)
4-Bay (SATA)
4-Bay (SATA)
CPU Model
1235u
1235u
1235u
N100
N100
8505
Expandable RAM (Max)
64GB
64GB
64GB
16GB
16GB
64GB
Flash Memory (System Disk)
SSD 128GB
SSD 128GB
SSD 128GB
eMMC 32GB
eMMC 32GB
SSD 128GB
SATA Drive Bays
6
8
-
2
4
4
M.2 SSD Drive Slots
2
2
4
2
2
2
RAID
JBOD/Basic/0/1/5/6/10
JBOD/Basic/0/1/5/6/10
JBOD/Basic/0/1/5/6/10
JBOD/Basic/0/1
JBOD/Basic/0/1/5/6/10
JBOD/Basic/0/1/5/6/10
Maximum Storage
196TB (6x 30TB + 2x 8TB)
256TB (8x 30TB + 2x 8TB)
32TB (4x 8TB)
76TB (2x 30TB + 2x 8TB)
136TB (4x 30TB + 2x 8TB
136TB (4x 30TB + 2x 8TB)
LAN Ports (RJ45)
2x 10GbE
2x 10GbE
1x 10GbE
1x 2.5GbE
2x 2.5GbE
1x 2.5GbE, 1x 10GbE
Product
Drive Bays
CPU Model
Expandable RAM (Max)
Flash Memory (System Disk)
SATA Drive Bays
M.2 SSD Drive Slots
RAID
Maximum Storage
LAN Ports (RJ45)
UGREEN NASync DXP6800 Pro
UGREEN NASync DXP6800 Pro
$1,079.99
$1,199.99
6-Bay (SATA)
1235u
64GB
SSD 128GB
6
2
JBOD/Basic/0/1/5/6/10
196TB (6x 30TB + 2x 8TB)
2x 10GbE
8-Bay (SATA)
1235u
64GB
SSD 128GB
8
2
JBOD/Basic/0/1/5/6/10
256TB (8x 30TB + 2x 8TB)
2x 10GbE
4 Slots (M.2 NVMe)
1235u
64GB
SSD 128GB
-
4
JBOD/Basic/0/1/5/6/10
32TB (4x 8TB)
1x 10GbE
2-Bay (SATA)
N100
16GB
eMMC 32GB
2
2
JBOD/Basic/0/1
76TB (2x 30TB + 2x 8TB)
1x 2.5GbE
4-Bay (SATA)
N100
16GB
eMMC 32GB
4
2
JBOD/Basic/0/1/5/6/10
136TB (4x 30TB + 2x 8TB
2x 2.5GbE
4-Bay (SATA)
8505
64GB
SSD 128GB
4
2
JBOD/Basic/0/1/5/6/10
136TB (4x 30TB + 2x 8TB)
1x 2.5GbE, 1x 10GbE

Specs

SKU 25898
Model DXP6800 Pro
Supported Languages English, Deutsch, Français, Español, Português, Italiano, 中文, 日本語
Drive Bays 6-Bay (SATA)
Operating System UGOS Pro
CPU Model 1235u
CPU Brand & Architecture Intel X86 12th Generation Intel® Core™ i5 10 Cores 12 Threads
Memory (RAM) 8GB DDR5
ODECC Supported
Expandable RAM (Max) 64GB
Flash Memory (System Disk) SSD 128GB
SATA Drive Bays 6
M.2 SSD Drive Slots 2
RAID JBOD/Basic/0/1/5/6/10
Maximum Storage 196TB (6x 30TB + 2x 8TB)
LAN Ports (RJ45) 2x 10GbE
PCIe Expansion 1x PCIe x4
Thunderbolt™ 4 Ports 2
High-Speed USB Ports (Front Panel) 2x Thunderbolt 4 (40Gb/s)
High-Speed USB Ports (Rear Panel) 2x USB-A (10Gb/s)
USB 2.0 (Rear Panel) 2x USB-A (480Mb/s)
SD Card Reader SD 4.0
HDMI 8K
Wi-Fi -
Product Dimensions L11.54×W10.16×H7.87 inches
Power Consumption 43.07 W (drive access)
24.91 W(drive hibernation)

Reviews

Customer Reviews

Based on 29 reviews
83%
(24)
17%
(5)
0%
(0)
0%
(0)
0%
(0)
A
Anonymous

So far, very easy to configure and set up. Installing drives and memory was made easy. Support has been quick when submitting tickets. Though sometimes when using the UGOS support/help links, it doesn't always show in English.

A
AKT

Loving it so far.

A
Amazon Customer
This one has much be

This one has much better HW than the other brands and cost much less. It works flawlessly so far. I know it's a newer venture for UGreen so I don't mind their software has less packages (as of now). But it does everything I want it to... And works nice with my 10g network... Blazing fast and adding the ssd's make a huge difference...

R
Robin Wallace
I purchased this ins

I purchased this instead of Synology because it offered two 10gb Ethernet ports and an i5 Intel CPU. Everything is fine except download speeds are slow! I have Cat8 cable, 10gb switch and got better speeds with my 2.5gb setup. I’m now getting 25mb download and was getting 60-70gb before. I hope an update fixes this. The App Store is sparse but I have faith in time it will grow.

G
Gene Olson
This is primarily a

This is primarily a hardware and Linux compatibility review. I only played with the bundled software for a few minutes. I am a long-time UNIX/Linux user, and I would probably be unsatisfied with NAS software from any vendor.My unit is a DXP6800, which supports 6 drives an a couple M.2 drives. I am currently running with four 18TB WD Red drives, and a 1 TB Sata SSD.I purchased DXP6800 after seeing the Youtube review by Electronics Wizardry. Following the instructions in the video, installation was easy. I am very grateful to Ugreen for sponsoring the video to help out users who want to run their own software. Without seeing it, I would have hesitated to purchase the device.Here is what I did to install Ubuntu 24.04 on the box.* I turned off the watchdog in the BIOS first thing. Until I did this, the box would reset after 120 seconds.* I was careful to make a copy of the original SSD image before reformatting the included SSD.* I installed a 32 GB Micron SIMM to bring the memory up to 40 GB.* I loaded Ubuntu 24.04 desktop from a flash drive. The BIOS does not support UEFI, so I used a DOS boot.* I raun the RAM test bundled with Ubuntu. It ran a full pass w/o errors.I am very pleased with the result. Ubuntu runs perfectly with the bundled device drivers. It's just install and go.The build quality is excellent. The enclosed manual is excellent. It is necessary to take the case off only to install PCIe cards.Running Prime 95, the CPU ran no hotter than 85°C with factory settings, as reported by the lm-sensors package. Exceptional.After fooling with the BIOS fan settings for a couple hours, I learned how to set them so the disk temps at idle in my 73°F room never exceeded 40°C, even when the disks were near max effort. See the photo for the settings I used. Temps reported by the smartmontools package.My drives all transfer data full speed simultaneously. So the internal SATA transfer rate exceeds 550 + 4*250 = 1550 MB/s. With 6 Sata SSDs it could be double that number.I didn't test the M.2 capability.The box accepted data full speed at 10G with no errors. However no single thread could transmit faster than 5Gb/s. Two threads could total 9 Gb/s. Connected to 2.5G ethernet, bidirectional transmission runs full speed.The single display appears to be HDMI 1.4. With that limitation, it works perfectly. I just used the display to install Ubuntu, and test Desktop operation.With my configuration, the box uses 50W, rising to 80W with full disk load. This is way too hot to put in a closed cabinet, unless you want to exercise your disk warranty.Fan noise is minimal at my settings, however disk noise is louder than a cheap computer case. MY WD drives are the quietest in their class, but the disk noise is very noticable. Loose disk mounts transfer seek noise out the front. My 7200 RPM drives cause the case to hum at a steady 120Hz. I had hoped to put the box in a living space, but I finally installed it in a storage room.I would have given the box 5 stars, except for the drive noise. I suspect this is a characteristic of all NAS cases, and I would complain about anything but a noise dampened case with drives on cushioned mounts. I'm very fussy, and I like *everything* else about the box.I purchased my system not from Amazon, but from a local vendor who sold me on the box. He deserves the commission.
